Enamelled Wire for Vehicle
• Enamelled wire for vehicle: PEWC use the most advanced and professional enamelled wire manufacture device from Europe, and also apply the on-line quality control to ensure the stability of quality.
• Enamelled wire for Electric vehicle (new-energy car) driving motor: Rectangular enamelled wire is the main products. The products characteristics are great corona resistance, thermal resistance, mechanical properties, ATF oil resistance, high PDIV and long product life.
Enamelled Wire for Vehicle
Product Description
Enamelled Wire for Vehicle
| Products Name | Products Code | Thermal Class(℃) | JIS | NEMA | IEC |
|---|---|---|---|---|---|
| Polyester-imide Enamelled Wire | PEWH☆ | 180 | 3202-8 | MW 30-C | 60317-8 |
| Modified polyester overcoat polyamide-imide Enamelled Wire | SSF-H☆ | 180 | — | — | — |
| Modified polyester overcoat polyamide-imide Enamelled Wire | AIEIW-300☆ | 200 | — | MW 35-C | 60317-13 |
| Polyester-imide overcoat polyamide-imide Enamelled Wire | AIEIW-200☆ | 200 | — | MW 35-C | 60317-13 |
| Inverter Surge-resistant Enamelled Wire | PIVW☆ | 200 | — | MW 35-C | 60317-13 |
| Polyamide-imide Enamelled Wire | AIW-220☆ | 220 | JCS 2334 | MW 81-C | 60317-57 |
| Polyimide Enamelled Wire | ML | 240 | — | MW 16-C | 60317-46 |
| Polyamide-imide rectangular Enamelled Wire | HEVW-220C | 220 | — | MW 84-C | 60317-58 |
| Polyimide rectangular Enamelled Wire | HEVW-240C | 240 | — | MW 20-C | 60317-47 |
| HEVW-240P | 240 | — | MW 20-C | 60317-47 | |
| HEVW-240CF | 240 | — | MW 20-C | 60317-47 |
Enamelled Wire for Vehicle
